Product Description
High-Frequency Vibration Technology
Operating at 3500 r/min with 10mm amplitude, the GZD Plate Compactor delivers rapid, uniform compaction across the entire plate surface. According to industry standards, vibration frequency directly affects compaction efficiency—higher frequencies achieve better density results. The high-frequency vibration penetrates deep into soil layers (up to 30cm effective depth), achieving optimal density with fewer passes. Reduces compaction time by up to 30% compared to lower-frequency alternatives.
Versatile Soil & Asphalt Compaction
Whether compacting sand, gravel, crushed stone, or hot asphalt, the GZD Plate Compactor adapts to the material. The heavy-duty base plate distributes force evenly, preventing surface damage while achieving target density. Ideal for road construction, driveway installation, landscape preparation, and pipeline foundation work. The machine handles materials with low inter-particle cohesion and friction, making it perfect for granular soils and asphalt mixtures.
Reversible Operation Option
The GZD-160 two-way model features forward and reverse travel capability through adjustable exciter positioning, eliminating the need to manually reposition the machine in confined spaces. Perfect for trench work, foundation compaction, and areas with limited maneuvering room. The hydraulic/mechanical bidirectional system increases productivity by reducing non-productive positioning time. Climbing ability reaches 25% grade.
Rugged Construction for Heavy Use
Built with reinforced steel components and premium bearings, the GZD Plate Compactor withstands the rigors of daily construction use. The 5.5-7HP engine provides reliable power in demanding conditions, while the protective frame guards against jobsite impacts. Features include rubber shock-absorbing design for operator comfort and extended equipment life. Minimal maintenance requirements maximize uptime.
Technical Specifications
| Parameter | GZD-90T | GZD-160 | GZD-160 Two-Way |
| Power | 5.5-7HP | 5.5-7HP | 5.5-7HP |
| Vibration Frequency | 3500 r/min | 3500 r/min | 3500 r/min |
| Amplitude | 10mm | 10mm | 10mm |
| Excitation Force | 20KN | 20KN | 15KN |
| Weight | 60kg | 70kg | 150kg |
| Compaction Depth | 25-30cm | 25-30cm | 25-30cm |
| Travel Mode | Forward | Forward | Reversible |
| Climbing Ability | 25% | 25% | 25% |
| Plate Size | Standard | Standard | Large |
| Origin | China | China | China |
| Brand | GZD | GZD | GZD |
| Stock Status | Ready Stock | Ready Stock | Ready Stock |
Profitable Applications
Customization
Customize your concrete joint cutting machine with GZD! Our road cutting machine, originating from China, offers versatility with blade diameters of 40cm and 50cm. Choose a blade size between 600mm to 700mm, powered by a reliable 13HP engine. Enjoy peace of mind with a 1-year warranty on your concrete floor cutting machine. Achieve cutting depths of up to 150mm!
Dealer Customization Policy
FAQ
Absolutely. We offer comprehensive OEM and ODM services for your branding needs, including custom logos, personalized paint colors, and specific packaging designs.
Just 1 unit to start. We encourage sample testing. For bulk orders or mixed-container shipments, we provide aggressive wholesale tier pricing.
We manage the heavy lifting. All equipment is secured in export-grade wooden crates. We offer Sea, Air, and Train freight options, handle all export documentation, and specialize in mixed-container consolidation to minimize your shipping costs.
Yes. Every machine ships with intuitive operation manuals and video tutorials. For major fleet purchases, we provide dedicated remote video training to ensure your team is ready to go.
Downtime kills profits. You have 24/7 access to our technical troubleshooting team. We also maintain a massive inventory of genuine spare parts ready for immediate air freight.
We balance rugged, commercial-grade quality with direct wholesale pricing. We aren’t selling cheap, disposable machines. You are investing in high-ROI equipment backed by a reliable supply chain and flexible payment terms.
